Part Number: BN10-NT15-6-P75Z
BN10-NT15-6-P75Z
Details & Specifications

BodyBrass, Nickel Plated
ContactPhosphor Bronze, Gold Plated
Coupling NutBrass, Nickel Plated
DielectricPTFE
PinPhosphor Bronze, Gold Plated
Dielectric Withstanding1500 Volts RMS Maximum
Durability500 mating cycles
Impedance75 ohms
Max. Frequency4 GHz
Temperature Range-65 to +165 degrees C
Working Voltage500 Volts RMS Maximum
Additional InformationPlease note: 75 ohm N types are not intermateable with standard 50 ohm N types.

Return Loss [VSWR]:

500MHz - 37.00dB [1.030]
1000MHz - 32.00dB [1.053]
2000MHz - 30.00dB [1.065]
3000MHz - 18.00dB [1.29]
3800MHz - 17.00dB [1.33]

Technical Illustration
BN10-NT15-6-P75Z
